UH03200 NXT  Head cleaner

Product Details

• Product Name: FUJI NXTH12 Nozzle Rod Cleaning Fixture, also referred to as a "working head cleaning machine cleaning fixture".
• Part Numbers: The primary part numbers associated are UH03200 and QK00C00 (or QK00C01).
• Compatibility: It is designed for use with the FUJI NXT series of SMT machines, specifically compatible with the H12 head.
• Function: This fixture automates the process of cleaning debris and accumulated dirt from the air routes and syringes inside the machine's placement heads, a task that typically requires skill and experience when performed manually. The system can perform both air and oil cleaning.
• Benefits: According to Fujintai, automating this process reduces operator work time significantly (from 41 minutes to 8 minutes in one evaluation) and ensures stable cleaning results without the variance caused by manual operator mistakes. It also includes an inspection function that measures the air flow rate after cleaning to ensure proper operation.
