UNITTA 204-2GT belt (6mm wide)

UNITTA 204-2GT belt (6mm wide)
 Technical Specifications

• Part Number: 204-2GT-6 (The "6" at the end explicitly designates the 6mm width).
• Pitch: 2 mm (The distance from the center of one tooth to the center of the next).
• Total Length: 204 mm (The full circumference of the closed loop).
• Number of Teeth: 102 teeth.
• Width: 6 mm.
• Tooth Profile: GT (Circular/curved arc tooth profile which reduces backlash, slippage, and noise).
• Tensile Cord Core: Fiberglass (Provides excellent strength, dimensional stability, and eliminates stretching over time).
• Body Material: Neoprene (Synthetic rubber that provides wear, oil, and chemical resistance)

 Key Performance Advantages

• Anti-Backlash & Smooth Motion: Its unique curved tooth design offers seamless engagement with standard 2GT pulleys. This is critical for avoiding ghosting or dimensional errors in 3D printing layers.
• No Elongation: Thanks to the fiberglass reinforcement core, the belt maintains a highly stable tension without loosening or stretching during constant bidirectional shifts.
• Low Noise & Low Dust: Engineered with high-durability tooth-facing material that reduces operational friction and limits the accumulation of rubber powder.
