UR3K-025GM150 HONSBERG FLOW SWITCH

UR3K-025GM150 HONSBERG FLOW SWITCH
Technical Specifications

• Model Type: UR3K-025GM150 (Goods / Article Number: 940241)
• Nominal Diameter: DN 025 (1 inch G internal thread connection)
• Switching Range (Water / H2O): Adjustable between 12 to 15 l/min
• Max Pressure (PN): 25 bar
• Housing & Connection Material: Nickel-plated brass
• Seal Material: NBR
• Media Temperature Range: -20 °C up to +110 °C
• Ambient Temperature Range: -20 °C up to +70 °C
• Electrical Connection: Plug connector DIN 43650-A / ISO 4400
• Switching Contact: Reed switch (NO contact, max. 230 V AC, 1 A, 50 VA)
• Ingress Protection: IP65
• Weight: ~0.65 kg
