UXT45 MOTEE limit Sensor for flipper conveyor
Technical Specifications
Brand/Manufacturer:
Model Designation: UXT45 (The "T" indicates the specific T-shape physical housing profile of the UX45 series)
Output Configuration: NPN Open Collector (A PNP variant is available as UXT45P)
Operating Voltage: 5V DC to 24V DC (±10%)
Response Frequency: High-speed 3 kHz, allowing it to track fast-moving mechanical arms or flipper gates
Protection Class: IP50 dust resistance
Cable Style: Standard 2-meter flexible wire (with optional drag-chain bend resistance for moving components)
Application on a Flipper Conveyor
In a flipper conveyor system (often used to change the direction of packages or flip PCBs over), the UXT45 serves as a non-contact, highly precise limit switch.
Position Monitoring: It detects the structural "flag" or metal tab attached to the pivoting flipper arm when it reaches its maximum open or closed angle.
High Reliability: Because it uses an infrared beam across the slot instead of a physical lever, it eliminates mechanical wear from rapid flipping cycles.
