UYUE 946C Desoldering Rework Station Aluminium Heating plate 220V BGA SMD
Key Specifications

• Power Rating: 600W to 800W (depending on the specific batch/version)
• Input Voltage: AC 220V (50/60Hz)
• Heating Area: 200 x 200 mm aluminum heating plate
• Temperature Range: 50°C to 350°C (up to 400°C on some variants)
• Temperature Display: 3-digit LED display with 1°C resolution
• Control System: Closed-loop PID control
• Dimensions: Approx. 215 x 215 x 135 mm (plate size 200 x 200 x 20 mm)
• Weight: ~3 kg to 3.5 k
• Main Features & Applications
  • Uniform Conduction: Thick aluminum plate designed to transfer heat evenly across printed circuit boards.
  • BGA & SMD Rework: Ideal for preheating boards to safely remove or reflow high-pin-count ICs, PLCC, QFP, SOIC, and LED strips without warping the PCB.
  • Phone Screen Repair: Commonly used at 80°C–100°C to soften adhesive for smartphone LCD and touch-screen separation.
  • Safety & Build: Features an anti-static structure and integrated digital thermostatic control.
