V2ZM10 (125100) 21-240V ACDC TELE TIMER

V2ZM10 (125100) 21-240V AC/DC TELE TIMER
Key Specifications & Features

• Supply Voltage: 12V to 240V AC/DC (universal range)
• Functions: 10 selectable timing functions (including delay-on-make, single-shot, interval, etc.)
• Time Ranges: 10 adjustable ranges from 0.05 seconds up to 100 hours
• Output Contacts: 1 SPDT (Single Pole Double Throw / 1 changeover) contact rated up to 8A at 250V AC
• Mounting: 22.5 mm wide DIN rail mount (EN 60715)
• Indicators: LED displays for supply voltage/timing status (U/T) and relay status (R)

Would you like help with:

• The wiring diagram or terminal pin layout?
• Explaining a specific timer function (e.g., E, R, Wu)?
• Finding purchasing options in your region?Key Specifications & Features
  • Supply Voltage: 12V to 240V AC/DC (universal range)
  • Functions: 10 selectable timing functions (including delay-on-make, single-shot, interval, etc.)
  • Time Ranges: 10 adjustable ranges from 0.05 seconds up to 100 hours
  • Output Contacts: 1 SPDT (Single Pole Double Throw / 1 changeover) contact rated up to 8A at 250V AC
  • Mounting: 22.5 mm wide DIN rail mount (EN 60715)
  • Indicators: LED displays for supply voltage/timing status (U/T) and relay status (R)
