V5IK60A-CF servo motor assay

V5IK60A-CF servo motor assay
Core Technical SpecificationsThe standard operating parameters for this industrial motor assembly include:

• Power Output: 60 Watts
• Input Voltage: 200V – 230V AC (Single Phase)
• Frequency: 50 / 60 Hz
• Rated Motor Speed: ~1300 to 1550 RPM (Before gear reduction)
• Current Draw: Approx. 0.7 Amperes
• Shaft Style: GU type pinion shaft (engineered to integrate directly with gearheads)

Structural Components of the AssemblyWhen sourcing or replacing this unit as a complete assembly, it usually consists of three integrated sections:

• Motor Block (5IK60GU-CF): The main single-phase induction driver.
• Gearhead (GU Type): A parallel shaft gearbox (such as the 5GU□KB series) that bolts directly onto the pinion shaft to reduce RPM and amplify torque.
• Brake Pack / Controller: An electronic add-on used to achieve instantaneous stopping, rapid bi-directional rotation, and thermal safety over-temperature detection.
