VB-2211 Omron Limit Switch

VB-2211 Omron Limit Switch
Key Specifications

• Actuator Type: Two roller plungers in a single compact housing.
• Current & Voltage Rating: 10 Amps at 250 VAC.
• Contact Configuration: SPDT (1NO + 1NC per circuit).
• Protection Class: IP67 (dust-tight and waterproof).
• Mechanical Life: Up to 5 million operations.

Main Features

• Durable Build: Features an integrated head box for better sealing and head strength.
• Oil Filter System: Automatically discharges water or oil if it enters the plunger section.
• Easy Wiring: Equipped with standard screw terminals and threaded conduit inlets.
