VFD2A8MS21ANSAA POWER MODULE

VFD2A8MS21ANSAA POWER MODULE
Core Specifications

• Series: MS300 Series (Standard Compact Drive)
• Power Rating: 0.5 HP / 0.4 kW
• Input Voltage: 230V, 1 Phase
• Output Current: 2.8 A (Heavy Duty), up to 5 A max
• Frequency Range: 0 to 599 Hz
• IP Rating: IP20

 Key Features

• Motor Control: Supports open-loop control for both Induction Motors (IM) and Permanent Magnet (PM) motors.
• Integrated Functions: Includes a built-in brake chopper, built-in PLC program (2K steps), and Safe Torque Off (STO) capability.
• Communication: Comes with built-in RS-485 (Modbus) support and a detachable digital keypad for local/remote operation.
