VG342R-5DZ-10F SOLENOID VALVE

VG342R-5DZ-10F SOLENOID VALVE
Part Number Breakdown

• VG342: Valve base series (3-port pilot-operated poppet valve).
• R: External pilot type.
• 5: 24V DC rated voltage.
• DZ: DIN terminal electrical entry equipped with an indicator light and surge voltage suppressor.
• 10: 1-inch connection port size.
• F: G-type thread standard (BSPP).

Key Technical Specifications

• Port Size: 1 inch thread.
• Thread Type: G (BSPP).
• Operating Pressure Range: -0.1 to 0.9 MPa (suitable for low pressure or vacuum systems).
• Maximum Pilot Pressure: 0.9 MPa.
• Maximum Flow Rate: 9787 L/min.
• Flow Coefficient (Cv): 11.4.
• Seal Material: High-durability rubber.
• Lubrication: Not required (lubrication-free design).

Primary Product Features

• Universal Flow Paths: The external pilot design allows the valve to be utilized flexibly as either a selector valve or a divider valve.
• Changeable Actuation: Can be configured for normally closed (NC) or normally open (NO) operations depending on the piping configuration.
• Vacuum Capabilities: Capable of handling negative pressure applications down to -0.1 MPa.
