VSA004 vibration sensor IFM
Key Specifications

• Measurement Range: -25 g to 25 g
• Frequency Range: 1 Hz to 10,000 Hz (10 kHz)
• Signal Output: 0 to 10 mA analog current output
• Operating Voltage: 7.2 V DC to 10.8 V DC
• Sensitivity: 142 µA/g
• Accuracy: Low linearity deviation of 0.2% with less than 3% repeatability error.

Physical & Environmental Features

• Housing Material: Rugged, compact cylindrical 316L stainless steel (1.4404).
• Connection Type: Integrated 3-metre PUR shielded cable with a drag chain suitability rating.
• Ingress Protection: IP67 rating (dust-tight and water immersion resistant).
• Mechanical Resilience: Built-in overload protection up to 500 g.
• Operating Temperature: -20 °C to 80 °C.
