VTF18-4N1612 photoelectric Proximity sensor

VTF18-4N1612 photoelectric Proximity sensor
Key Technical Specifications

• Sensing Range: 3 mm to 90 mm (maximum reach of 100 mm)
• Light Source: Focused infrared LED (3 mm light spot at 50 mm distance)
• Output Type: NPN
• Switching Mode: Light/Dark switching, selectable via control wire
• Supply Voltage: 10 V DC to 30 V DC (Current consumption: 30 mA)
• Housing: Cylindrical M18x1, 63.6 mm length, made of durable PBT/PC plastic
• Environmental Rating: IP67
