Automatic Wave Soldering Machine N200
Automatic Wave Soldering Machine N200 lead-free dual Wave Soldering Machine
Technique : wave, Operating mode : PLC-controlled, Applications : for PCB, Power : Max.: 16,000 W, Min.: 3,000 W
Specification/Additional Details
- Automation Grade : Automatic
- Brand : Jaguar Automation
- Model Name/Number : N200
- Technique : Wave
- Operating mode : PLC-controlled
- Applications : for PCB
- Total/running power : 16KW/3KW
- Length of heating zones : 500mm
- Air supply : 0.5MPa
- Preheating method : IR(standard)
- Preheating power : 220V 5KW
- Control method : Press key +PLC
- Preheating time : About 10-15mins for setting 150°C
- Solder type : Lead-free / Sn-Pb
- Solder pot capacity : 180KG
- Solder pot temperature : 300 °C
- Solder power : 380V 6KW
- Solder temp. control method : PID&SSR
- Wave crest drive power : 500W 220V
- Warm-up time of solder : About 120mins for setting 250 °C
- PCB width : 200mm
- Conveyor speed : 0-1800mm/min
- Conveyor direction : L to R (R to L optional)
- Conveyor angle : 4-6 °
- Flux pressure : 3-5 bar
- Flux capacity : 3.2L
