WKC4.4T-1-RSC4.4TTXL Proximity sensor
Key Product Specifications

• Manufacturer: TURCK (Part ID: 6625639).
• Connection A: M12 × 1 female connector, angled, 4-pin, A-coded.
• Connection B: M12 × 1 male connector, straight, 4-pin, A-coded.
• Cable Length: 1 metre (Indicated by the "-1-" in the part number).
• Cable Jacket Material: PUR (Polyurethane), part of the TXL premium series.
• Wire Cross-Section: \(0.34\text{ mm}^2\) (4 cores).
• Electrical Ratings: Up to 250 V and 4 A.
• Environmental Ratings: Submersible and resilient with IP67 and IP69K sealing. [1, 2, 3, 4, 5, 6]

Performance Highlights

• Drag Chain Compatibility: Specifically qualified for flexible applications and continuous motion.
• Industrial Resilience: Highly resistant to welding sparks, chemical exposure, UV radiation, and typical industrial oils.
• Eco-Friendly Design: Formulated completely free from halogens, silicone, PVC, and LABS (lacquer-wetting impairment substances)
