WL12L-2B530 SICK, Photo Sensor, 18 m, NPN/PNP

WL12L-2B530 SICK, Photo Sensor, 18 m, NPN/PNP

• Sensing Principle: Photoelectric retro-reflective sensor using autocollimation (coaxial optics) for zero minimum distance tracking.
• Sensing Range: 0 metres to 18 metres (when used with a standard reflector like the PL80A).
• Light Source: Visible red laser light (Class 2, 650 nm wavelength).
• Laser Spot Size: Extremely fine Ø 0.8 mm spot at a 300 mm distance.
• Supply Voltage: 10 V DC to 30 V DC.
• Output Type: Complementary NPN and PNP outputs.
• Switching Mode: Selectable Light-on / Dark-on switching.
• Response Time: \(\le \) 200 µs with a switching frequency of 2500 Hz.
• Adjustment: Built-in manual potentiometer to fine-tune sensitivity and focus.
• Connection Type: Standard M12 male plug, 5-pin connector.
• Enclosure Rating: Rugged IP67 / IP69K rated metal housing.
• Dimensions: 15 mm x 49 mm x 41.5 mm.
