WL18-3P430 Sick Sensor

WL18-3P430 Sick Sensor

Technical Specifications

• Sensing Range: Maximum up to 7 metres when paired with a
• Light Source: Visible red LED with a wavelength of approximately 645 nm.
• Supply Voltage: 10 V DC to 30 V DC.
• Switching Output: PNP type with complementary output functionality.
• Connection Interface: 4-pin M12 male connector.
• Enclosure Rating: IP67 dust and water protection.
• Physical Dimensions: 17.6 mm x 75.5 mm x 33.5 mm rectangular ABS housing.

Manufacturer Lifecycle Status

• Phase-Out Alert: According to official distributor bulletins from RS Components, the WL18-3P430 has been phased out by the manufacturer and is discontinued.
• Recommended Upgrade: The factory-direct modern migration replacement for this unit is part number WLA16P-24162100A00
