WLCA12-2-Q Limit sensor

WLCA12-2-Q Limit sensor
Key Technical Specifications

• Actuator Type: Adjustable Rotary Roller Lever (can be extended, shortened, or rotated).
• Action Type: Momentary (spring-returns to its starting position instantly upon release).
• Contact Configuration: SPDT / Double-Circuit (1 NO + 1 NC).
• Electrical Ratings: Maximum insulation voltage (Ui) of 380V with a thermal current (Ith) of 10A.
• Environmental Protection: Rated at IP66 / IP67, making it oil-proof, dust-tight, and highly water-resistant.
• Housing Material: Heavy-duty aluminum die-cast outer casing.
• Operating Temperature: -10°C to +80°C (without icing).

Core Applications

• Position Monitoring: Tracking the movement and precise travel constraints of physical machinery and industrial plants.
• Overtravel Protection: Acting as a physical safety cut-off switch to stop a motor or carriage if it travels past its designated boundary.
• Sequence Control: Triggering consecutive automated steps or "home" positions at the start of automated system sequences.
• Safety Circuits: Integrating into critical auxiliary machine interlocks to cut system power during physical faults.
