WLCA2-LD omron limit switch

WLCA2-LD omron limit switch
Key Specifications

• Actuator Type: Side rotary, standard roller lever with a radius of 38mm.
• Indicator: Equipped with an LED (rated for AC/DC 10 to 115V) that lights up during operation.
• Contact Form: 1a1b (equivalent to SPDT: 1 NO + 1 NC).
• Current Rating: Rated for 10A resistive load at 115VAC.
• Protection Level: IP67 rated, making it dust-tight and waterproof for harsh industrial environments.
• Operating Temperature: Ranges from -10°C to 80°C.

Mechanical & Operating Characteristics

• Operating Force (OF): Max. 13.34 N.
• Pretravel (PT): 15° ± 5°.
• Overtravel (OT): Min. 30°.
• Mechanical Life: Up to 15,000,000 operations.
• Electrical Life: Approximately 750,000 operations.
