Omron WLCA32-43 Heavy-duty Two-circuit Limit Switch

The Omron Automation and Safety WLCA32-43 is a heavy-duty, two-circuit limit switch from the WL-N series with a side rotary, fork lever lock actuator. It features an IP67 rating, making it dust-tight and waterproof for use in demanding industrial environments.

Specifications

• Manufacturer: Omron Automation and Safety
• Series: WL-N
• Actuator Type: Side Rotary, Fork Lever Lock (Yoke)
• Circuit: SPDT (Double Break/Double Make)
• Mounting Type: Chassis Mount
• Termination: Screw Terminal
• Current Rating: 10A (AC), 6A (DC)
• Voltage Rating: 125 V (AC), 30 V (DC)
• Ingress Protection (IP) Rating: IP67, indicating it is protected from dust and water immersion.
• Operating Temperature: -10°C to 80°C.
• Mechanical Life: 15,000,000 cycles.
• Electrical Life: 750,000 cycles.
• Operating Force: 1200 gf.
• Pretravel: 55°.
• Overtravel: 35°.
• Weight: Approximately 275 g.
• Conduit Size: G1/2.
