Omron WL-Series WLHL-LD Limit Switch

WLHL-LD Two-Circuit Limit Switch OMRON, Adjustable Rod Lever Limit Switch WLHL-LD Omron, WLHL-LD General Purpose Vertical Limit Switch

The Omron WLHL-LD is an industrial, general-purpose, 2-circuit limit switch with an adjustable rod lever and a built-in status indicator. It is a vertical-style switch designed for use in a variety of standard and environmentally challenging applications. The "LD" in the model name specifies that the switch is equipped with an LED indicator light.

Specifications

Features

• Built-in LED indicator: The "LD" variant includes a light to indicate when the switch is operated.
• Adjustable rod lever: The actuator is a rotating rod that can be adjusted from 25 mm to 140 mm to accommodate the application.
• Rugged and durable: Constructed with a high-quality metal body for reliable, long-lasting performance in industrial environments.
• Environmentally resistant: The switch has an IP67 rating, making it dust-tight and waterproof. This allows for use in harsh environments.
• Versatile application: The WL series includes multiple types that can be selected for general detection, high-frequency use, or spatter-resistant applications.
