WLNJ-30 Omron Limit Switch

WLNJ-30 Omron Limit Switch
Key Specifications

• Actuator Type: Flexible coil spring rod (4.8 mm diameter).
• Contact Configuration: SPDT (Single Pole Double Throw) with 2-circuit double-break contacts.
• Current Rating: 10 A at alternating current (AC).
• Ingress Protection: Certified IP67 rating, making it completely dust-tight and resistant to water immersion.
• Operating Temperature: Performs reliably between -10°C and +80°C.
• Conduit Size: Standard G1/2 threaded entry.

Performance Characteristics

• Flexible Actuation: The multi-turn coil spring mechanism responds to physical movement or contact from multiple directions, providing great setup versatility.
• Industrial Endurance: Built with high mechanical strength and strong resistance to vibration or high shocks.
• Safe Termination: The double-break structure ensures distinct electrical isolation and safe circuit interruption during everyday use. [1, 2, 3, 4, 5]

Common Applications

• Conveyor Lines: Used to detect misaligned items, tall boxes, or pile-ups.
• Machine Tools: Serves as safety or travel limits for moving machine heads.
• Automated Packaging: Ideal for counting passing objects with irregular profiles or varied orientations.
