WT100-2P1439 SICK SENSOR

WT100-2P1439 SICK SENSOR
Key Features and Technical Data:

• Functional Principle: Photoelectric proximity sensor (Energetic).
• Sensing Range: 0 mm to 1200 mm (max) or 0 mm to 900 mm (typical).
• Output Type: PNP, Light/Dark Switching via rotary switch.
• Light Source: Visible Red LED (680 nm).
• Supply Voltage: 10 V DC ... 30 V DC.
• Response Time:  0.5 ms.
• Switching Frequency: 1,000 Hz.
• Connection: Cable, 3-wire, 2 m (PVC).
• Housing: Plastic (ABS/PC/POM), IP67 protection.
• Adjustment: Potentiometer, 270°.
• Operating Temp: –25 °C ... +55 °C.
