Sick WTB250-2P1141 Photoelectric Sensor

Sick WTB250-2P1141 6044680 Photoelectric Proximity Sensor, Background suppression, 150 mm ~ 500 mm Sensing range, PNP, Light-on/dark-on switching, Visible red light, 10 V DC ~ 30 V DC Supply voltage, Potentiometer 2 turns, Cable, 4-wire, 2 m

Specification/Additional Details

• Sensor Type : Photoelectric Proximity Sensor
• Functional principle detail : Background suppression
• Brand : Sick
• Model : WTB250-2P1141
• Sensing Range : 150 mm to 500 mm
• Type of light : Visible red light

• Switching output : PNP

• Switching mode : Light-on/dark-on switching

• Switching mode selector : Selectable via L/D control cable

• Response time : 3 ms

• Switching frequency : 160 Hz

• Connection type : Cable, 4-wire, 2 m

• Ambient operating temperature : -25  DegreeC to +55  DegreeC

• Enclosure rating : IP67
