XCKP2102P16 (G11) ZCP21 + ZCE0Limit sensor

XCKP2102P16 (G11) ZCP21 + ZCE0 Limit sensor
Components of XCKP2102P16This model is typically assembled from the following modular components:

• Body (ZCP21): A 2-pole (1NC + 1NO) snap-action limit switch body.
• Head (ZCE02/ZCE0): Steel roller plunger operator.
• Cable Entry (P16): M16 x 1.5 cable entry.

Key Specifications

• Actuator Type: Linear steel roller plunger.
• Contact Configuration: 1 NC + 1 NO (Snap-action).
• Protection Rating: IP66/IP67 (dust tight and protected against water jets/temporary immersion).
• Electrical Connection: Screw-clamp terminals.
• Material: Plastic (Thermoplastic) body.
• Durability: 10 million mechanical cycles.
• Operating Speed: 0.5 m/s maximum.

Key Features

• Modular Design: Part of the Osiconcept series, allowing for interchangeable heads (ZCE) and cable entries.
• Robustness: High vibration and shock resistance.
• Compact Format: Suitable for tight spaces in conveyor technology, gates, and manufacturing equipment.
