Telemecanique XCMD2102L1 Limit Switch

Telemecanique XCMD2102L1 Limit Switch Steel Roller Plunger, 1NC 1NO, Snap Action, 6A max. Contact Current, 1.5A / 240V AC Contacts Rating, 1.5A / 24V DC Contacts Rating, Metal Roller Ø11;6mm, 1m Cable, IP66, IP67, IP68

Specification/Additional Details

• Contact Configuration : NO + NC
• Brand : Telemecanique
• Model : XCMD2102L1
• Product Type : Limit Switch
• Actuator Type : Metal Roller Plunger
• Output configuration : NO + NC

• Contact current max. : 6A

• AC contacts rating @R (at resistive load) : 1.5A / 240V AC

• DC contacts rating @R (at resistive load) : 1.5A / 24V DC

• Switched voltage : max. 250V AC, max. 250V DC

• Connection : 1m Cable

• IP rating : IP66, IP67, IP68

• Operating temperature : -25 to 70°C

• Mounting holes pitch : 20mm

• Action Type : Snap Action
