XCMD2102L2 telemecanique sensor

XCMD2102L2 telemecanique sensor
Key Specifications

• Sensor Type: Limit switch (miniature XC Standard series)
• Actuator: Metal / steel roller plunger (spring return, 30° cam approach)
• Contact Configuration: 1 NC + 1 NO (snap action with positive opening)
• IP Rating: IP66, IP67, IP68 (dust-tight and water-resistant)
• Body Material: Zamak (zinc alloy) metal housing
• Electrical Connection: 2-meter pre-wired cable
• Ratings: Max 250V AC/DC, up to 6A
• Operating Temperature: -25°C to 70°C
• Mechanical Durability: 10,000,000 cycles
•
