XCMD2110L1 Telemecanique Sensor
- Actuator Type: Metal end plunger (pin plunger Ø7mm).
- Contact Configuration: 1 Normally Closed (NC) + 1 Normally Open (NO) snap-action contacts.
- Housing Material: Metal (Zamak) body and head for robust durability.
- IP Rating: IP66, IP67, and IP68, providing high protection against dust and water ingress.
- Electrical Connection: Pre-wired with a 1-meter cable (5 x 0.75 mm² wire composition).
- Electrical Ratings:
- Max AC Contact Current: 6 A at max 250 V AC.
- AC-15 utilization category: 1.5 A at 240 V.
- DC-13 utilization category: 0.1 A at 250 V DC (or 3 W at 24 V DC).
- Mechanical Durability: Rated for 10 million operational cycles.
- Dimensions (Body): 30 mm (W) x 50 mm (H) x 16 mm (D).
- Operating Temperature: -25 to 70°C.
- Certifications: UL 508, CSA C22.2 No 14, CCC, EN/IEC 60204-1, EN/IEC 60947-5-1.
