XD2PA22CR Schneider Joystick Controller

XD2PA22CR Schneider Joystick Controller
Technical SpecificationsBased on the official Schneider Electric Product DataSheet, the key specifications are:

• Contact Configuration: 2 Normally Open (NO) contacts.
• Operating Positions: 2 positions with 1 notch per direction.
• Ratings:
  • Rated Operational Current: 3 A at 240 V (AC-15) or 0.27 A at 250 V (DC-13).
  • Insulation Voltage (): 600 V conforming to IEC 60947-1.
• Protection: IP65 or IP66 (dust and water-resistant) and IK06 (impact resistance).
• Durability: 1,000,000 mechanical cycles and 100,000 electrical cycles.
• Mounting: Standard 22.5 mm diameter panel cut-out with screw clamp terminals.
