XS1N18PC410 TELEMECANIQUE SENSOR
Key Specifications

• Sensor Type: Inductive proximity sensor (OsiSense XS series)
• Housing Size: Cylindrical M18 x 1 thread, 40 mm length
• Detection Range: 5 mm (flush mountable / embedded)
• Supply Voltage: 12 to 24 V DC (limits: 9–36 V DC) with reverse polarity protection
• Output Type: PNP, discrete, 4-wire (1 NO + 1 NC complementary output)
• Switching Capacity: Max 200 mA with overload and short-circuit protection
• Switching Frequency: Up to 2,000 Hz
• Electrical Connection: Pre-cabled (2-meter PVC cable with 4 x 0.22 mm² composition)
• Enclosure Material: Nickel-plated brass body with PPS front sensing face
• IP Rating: IP65, IP68 conforming to IEC 60529
• Operating Temperature: -25 °C to 70 °C
• Certifications: UL, CSA, CE, Tüv
