XS212B4PAL2 Telemecanique Sensor

XS212B4PAL2 Telemecanique Sensor
Technical Specifications

• Sensor Type: Inductive Proximity Sensor (OsiSense XS series)
• Housing Form: Cylindrical barrel, M12 x 1 thread
• Body Length: 37 mm
• Sensing Distance (Sn): 8 mm (non-flush mountable)
• Supply Voltage: 12 to 24 V DC (limits: 10–36 V DC)
• Output Logic / Type: PNP, 3-wire, Discrete 1 NO
• Switching Frequency: Up to 2000 Hz
• Current Rating: 200 mA max with overload/short-circuit protection
• Connection: 2-meter PVC cable
• IP Rating: IP65, IP67, IP69K
