YSRW-16-26 (191197 ) smc shock absorber

YSRW-16-26 (191197 ) smc shock absorber
Technical Specifications

• Size: 16.
• Stroke: 26 mm.
• Cushioning: Self-adjusting with a soft/progressive characteristic curve.
• Max. Energy Consumption: 35 J per stroke and 68,000 J per hour.
• Max. Impact Speed: 3 m/s.
• Max. Stop Force: 2,000 N.
• Reset Time: 0.3 seconds at room temperature.
• Weight: Approximately 190 g.
• Mounting: Installed via a lock nut in any position.
• Material: Galvanised steel housing with a high-alloy steel piston rod and NBR
