YW1S-3E20 idec switch

YW1S-3E20 idec switch
Key Specifications

• Switch Type: Rotary Selector Switch, Non-Illuminated.
• Positions: 3 positions with a 45° angle of throw.
• Function: Maintained (stays in the selected position).
• Contact Configuration: 2NO (Normally Open).
• Electrical Rating:
  • AC: 10A at 120V (up to 600V insulation rating).
  • DC: 8A at 24V.
• Mounting: Fits a standard 22mm panel cutout.
• Protection Rating: IP65 from the front panel (dust-tight and water-resistant) and IP20 for finger-safe screw terminals. element14 India +5

Product Features

• Modular Design: Features removable operators and 10mm thick contact blocks, making installation and removal easier.
• Safety: Equipped with finger-safe screw terminals and compliant with international standards including UL, c-UL, CCC, and EN.
• Construction: Heavy-duty rugged construction with a black plastic bezel and a prominent round actuator
