YWF.B2S-175-060AB20 Cooling Fan

YWF.B2S-175-060AB20 Cooling Fan
Technical SpecificationsAccording to official Dunli Electric product documentation, the exact parameters for this specific model are:

• Rated Voltage: 220V / 230V AC
• Frequency: 50 Hz
• Input Power: 53 Watts
• Current: 0.23 Amps
• Speed: 2550 RPM
• Airflow: 410 m³/h (at free delivery)
• Noise Level: 63 dBA
• Operating Temperature: -30°C to +60°C
• Certifications: CCC, CE

Dimensions and Construction

• Impeller Diameter: Φ 175 mm
• Design Type: Backward-curved motorized impeller, ensuring minimal dust buildup and efficient air delivery against system static pressure. [1, 2]

Cross-References & Equivalent Part NumbersThis specific motor design is frequently listed across various supplier channels using equivalent permutations of the model number, including:

• YWF.B2S-175-060AB00
• B2S-175/060AX20
• B2S-175-06AX20 [
