Omron Limit Switch Z-15GD-B General-Purpose Basic Snap-action Switch

Omron Snap-action Z-15GD-B Limit Switch

The Z-15GD-B is a general-purpose basic snap-action switch manufactured by Omron Automation and Safety. It features a short spring plunger actuator and a single-pole double-throw (SPDT) circuit. It is part of Omron's Z series, which is known for high precision and reliability.

Specifications

• Actuator: Short spring plunger.
• Circuit: Single-pole double-throw (SPDT).
• Termination: Screw terminals.
• Contact rating (AC): 15A at 125/250 VAC.
• Contact rating (DC): 6A at 30 VDC.
• Mounting type: Chassis mount.
• Operating force: 3.43 N (350 gf).
• Operating temperature: -25 to 80°C (-13 to 176°F).
• Mechanical life: 20 million cycles.
