Z-15HQ-B Omron micro switch
Key Specifications

• Brand / Manufacturer: Omron Automation and Safety
• Series / Part Number: Z-series, Model Z-15HQ-B
• Circuit / Form: SPDT (Single Pole Double Throw)
• Switch Function: On-Mom (Momentary)
• Current Rating: 15A (AC), 2A (DC)
• Voltage Rating: 125V / 250V AC
• Actuator Type: Overtravel plunger
• Contact Gap: 0.25 mm (high-sensitivity model 'H')
• Termination Style: Screw terminal
• Mounting Style: Panel mount
• Ingress Protection: IP00 (General-purpose)
• Operating Temperature: -25°C to +80°C
• Mechanical Life: 20,000,000 cycles
• Electrical Life: 500,000 cycles
