Optex Z2D-80P Photoelectric Diffuse-reflective Type Sensor

Optex Z2D-80P Photoelectric Diffuse-reflective Type Sensor 10 to 30 VDC 20mA PNP LO/DO Switch Selectable,
Optex Z2D-80P Diffuse Sensor PNP Output 800mm 2M

Brand : OPTEX
Model : Z2D-80P
Sensing Type : Diffuse-reflective Type
Sensing Distance : 800mm
Light Source : Red LED
Supply Voltage : 10V to 30V DC
Current Consumption : 20mA
Response Time: .5ms
Sensitivity Adjustment : 1-turn Potentiometer
Control Output : NPN/PNP type Open collector Max. 100 mA/30 VDC
Output Mode : Light ON / Dark ON Switch Selectable
Protection : IP67
Connection Type : Cable 2M
