ZB1-VPN3-L4-A vacuum pressure switch

ZB1-VPN3-L4-A vacuum pressure switch
Part Breakdown

• Brand: SMC Pneumatics
• Series: ZB Series Compact Vacuum Unit
• Design: Valve and Port Assembly (V port)
• Compatibility: Designed to accept compatible digital pressure sensors or vacuum pressure switches [1, 2, 3]

What does it do?A vacuum pressure switch is a control device. It senses the negative air pressure (P < 0 kPa) inside the vacuum line. When the vacuum reaches your desired target (your setpoint), the switch triggers an electrical signal. This confirms that a part has been securely picked up by an automated suction cup, or that the system is safe to proceed to the next step.
