ZH10BS-06-06 smt Filter

ZH10BS-06-06 smt Filter

Key Specifications

• Brand/Model: SMC ZH10BS-06-06  (Legacy model, updated to version ZH10BSA-06-06)
• Nozzle Diameter: 1.0 mm
• Port Size: 6 mm one-touch fittings for both supply (SUP) and vacuum (VAC)
• Max Vacuum Pressure: Up to -88 kPa (- 마치 26 inHg)
• Suction Flow Rate: 24 L/min
• Features: Built-in exhaust silencer, compact resin body, and point-of-use design

Application in SMT LinesIn Surface Mount Technology (SMT) and pick-and-place automation, this unit generates local vacuum pressure for component handling nozzles. Because fine dust or debris from components can clog the tiny Venturi nozzle, manufacturers recommend installing an external suction filter upstream on the vacuum line. Are you looking for a replacement suction filter part number to use alongside this ejector, or do you need help finding compatible tubing and fittings for your setup?
