ZHV30-BD Vacuum Flow amplifier

ZHV30-BD Vacuum Flow amplifier
Key Technical Specifications (ZHV30 Series)

• Maximum Suction Flow: 4590 L/min (ANR) at 0.5 MPa supply pressure.
• Maximum Discharge (Blow) Flow: 5310 L/min (ANR) at 0.5 MPa supply pressure.
• Supply Pressure Range: 0 to 0.7 MPa.
• Passage Diameter: \(\emptyset \) 30 mm.
• Vacuum Pressure: -6 kPa.
• Operating Temperature: -5 to 80 °C (no freezing or condensation).
• Weight: Approximately 526 g (unit only) or 587 g including the bracket.

Features and Use Cases

• Dual Functionality: It can generate a vacuum flow rate more than 3 times the supplied air volume or a blow-off flow rate more than 4 times the supplied air volume.
• Adjustability: Users can adjust the blow and vacuum flow rates by changing the internal nozzle position.
• Maintenance-Free: The unit has no moving parts, making it durable for industrial environments.
• Applications: It is commonly used for transporting bulk materials like powders, grains, or pellets, and for blowing away debris like machining chips or water droplets.

The "BD" suffix in the model number specifically indicates it includes a mounting bracket.
