ZL-B20P photoelectric Switch Sensor

ZL-B20P photoelectric Switch Sensor
Key Specifications

• Detection Distance: 3 mm to 400 mm (stable range: 25 mm to 400 mm)
• Supply Voltage: 12–24 VDC (±10%)
• Current Consumption: Under 25 mA
• Output Type: PNP open-collector (max load current: 100 mA, applied voltage: up to 30 VDC)
• Response Time: Less than 1 ms
• Protection Class: IP65 dustproof and waterproof
• Indicators: Red LED for operation status (ON), Green LED for power
• Adjustment: Mechanical 5-turn range-setting regulator
