ZPT13BS-J20-B5-A10 vac pad (bellows) w/buffer, ZP VACUUM PAD

ZPT13BS-J20-B5-A10  vac pad (bellows) w/buffer, ZP VACUUM PAD
Part Number Breakdown & Technical SpecificationsEvery block in the part number corresponds to a definitive technical parameter:

• ZPT: Component series indicating a vacuum pad assembly with a vertical vacuum entry direction and an integrated spring buffer.
• 13: The suction cup pad outer diameter is exactly ∅ 13 mm.
• B: The suction cup shape is a Bellows type, ideal for accommodating uneven heights or slightly angled target surfaces.
• S: The pad compound is Silicone Rubber, which offers white/clear aesthetics, zero-marking features, and an excellent operational temperature threshold ranging from -30°C to +200°C.
• J: Equipped with a Rotating Buffer mechanism to handle mechanical compression shock during product engagement.
• 20: The buffer spring stroke length is 20 mm.
• B5: The vacuum inlet port connection is an M5 x 0.8 female thread.
• A10: The overall component mounting arrangement is a M10 x 1 male thread.
