ZXQ2004 Relay module

ZXQ2004 Relay module
Core Specifications

• Input Signal: 4–20mA control signal
• Interface: 7-wire connector for electric actuators
• Display: 4 digital LEDs for valve position, design opening, and internal shell temperature
• Indicators: 9 LED lights indicating the positioner mode/status

Operational Features

• Proportional Control: Precise flow and pressure regulation
• Feedback Integration: Connects with feedback potentiometers via terminals (RO, RV, RS)
• Application: Used for automated industrial electric valves and motorized actuators

If you need specific wiring diagrams, calibration steps, or troubleshooting tips for the ZXQ2004, let me know how your system is set up
